Buy Hydac 1250495

1250495 Hydac 0660D010ON Filter element

Brand: HYDAC
Code: 1250495
Pressure Filter Elements for use in HYDAC filters

As the core of the filter, it is the filter element which performs the actual filtration and/or dewatering function in the housing. They consist of several pleated filtration and support layers which are placed as a cylinder around or inside the stabilizing support tube. These mesh packs are sealed by the end-caps. Regardless of the type of filter, flow direction through the filter elements is from out to in

The new Optimicron® filter elements have been optimised in respect of filtration performance and energy efficiency. They offer the best combination when it comes to separation efficiency, service life and differential pressure

Size: 0660

Installation : in inline filters

Filtration rating: 10 µm

Filter material of element: Optimicron®

Collapse stability: 20 bar

More information:
Length:
329 mm
Material:
Optimicron-Niederdruck
Weight:
1,2 kg
Outer diameter:
90,5 mm
Inner diameter (1):
48,2 mm
Size:
0660
Filter fineness:
10 µm

Check out any spare parts and components from the HYDAC catalog!


Do you want to order a 1250495 Hydac 0660D010ON Filter element with code: 1250495?


Leave your request on our website for immediate assistance!
